SMO WGS84 TO BNG
Convert between WGS84 (GPS latitude/longitude) and OSGB36 British National Grid (easting/northing) using a 7-parameter Helmert transformation. Pure Ruby, no external dependencies. Hydraulic modelling licences are expensive and I try to keep everything I build open source and free to use. If this gem saves you time, any support is genuinely appreciated.
Installation
gem install smo_wgs84_to_bngOr add to your Gemfile:
gem 'smo_wgs84_to_bng'Usage
Forward conversion (WGS84 → BNG)
Single point
require 'smo_wgs84_to_bng'
# Hash
SmoWgs84ToBng.convert_to_hash(id: 'GULLY_001', lat: 51.4779, lon: -0.0015)
# => { id: 'GULLY_001', easting: 538884.8, northing: 177321.9 }
# Hash with extra keys preserved
SmoWgs84ToBng.convert_to_hash(id: 'GULLY_001', lat: 51.4779, lon: -0.0015, material: 'concrete')
# => { id: 'GULLY_001', easting: 538884.8, northing: 177321.9, material: 'concrete' }
# Array (extra keys are dropped)
SmoWgs84ToBng.convert_to_array(id: 'GULLY_001', lat: 51.4779, lon: -0.0015)
# => ['GULLY_001', 538884.8, 177321.9]
# JSON string
SmoWgs84ToBng.convert_to_json(id: 'GULLY_001', lat: 51.4779, lon: -0.0015)
# => '{"id":"GULLY_001","easting":538884.8,"northing":177321.9}'Batch
points = [
{ id: 'A', lat: 51.4779, lon: -0.0015 },
{ id: 'B', lat: 55.9486, lon: -3.1999, material: 'iron' }
]
SmoWgs84ToBng.convert_many_to_hash(points)
# => [{ id: 'A', easting: ..., northing: ... }, { id: 'B', easting: ..., northing: ..., material: 'iron' }]
SmoWgs84ToBng.convert_many_to_array(points)
# => [['A', ..., ...], ['B', ..., ...]]
SmoWgs84ToBng.convert_many_to_json(points)
# => '[{"id":"A",...},{"id":"B",...}]'Reverse conversion (BNG → WGS84)
Single point
SmoWgs84ToBng.reverse_to_hash(id: 'GULLY_001', easting: 538885, northing: 177322)
# => { id: 'GULLY_001', lat: 51.4779, lon: -0.0015 }
SmoWgs84ToBng.reverse_to_array(id: 'GULLY_001', easting: 538885, northing: 177322)
# => ['GULLY_001', 51.4779, -0.0015]
SmoWgs84ToBng.reverse_to_json(id: 'GULLY_001', easting: 538885, northing: 177322)
# => '{"id":"GULLY_001","lat":51.4779,"lon":-0.0015}'Batch
points = [
{ id: 'A', easting: 538885, northing: 177322 },
{ id: 'B', easting: 325162, northing: 673961 }
]
SmoWgs84ToBng.reverse_many_to_hash(points)
SmoWgs84ToBng.reverse_many_to_array(points)
SmoWgs84ToBng.reverse_many_to_json(points)Accuracy
This gem uses a 7-parameter Helmert transformation based on the parameters published in the Ordnance Survey guide A Guide to Coordinate Systems in Great Britain. Typical accuracy is approximately 3–5 metres across mainland Great Britain. It is suitable for GIS, asset management, and field data workflows but is not appropriate for survey-grade or engineering applications where sub-metre accuracy is required.
Validation and Errors
All inputs are validated. The following error classes are defined:
| Class | Raised when |
|---|---|
SmoWgs84ToBng::Error |
Base class for all gem errors |
SmoWgs84ToBng::MissingIdError |
id is nil or missing |
SmoWgs84ToBng::MissingCoordinateError |
lat, lon, easting, or northing is nil |
SmoWgs84ToBng::InvalidCoordinateError |
Coordinate value is not numeric |
SmoWgs84ToBng::OutOfBoundsError |
Coordinates fall outside reasonable GB bounds |
Accepted bounds:
| Parameter | Min | Max |
|---|---|---|
| Latitude | 49.0 | 61.0 |
| Longitude | -8.5 | 2.0 |
| Easting | 0 | 700,000 |
| Northing | 0 | 1,300,000 |
Batch methods include the index of the offending point in the error message, e.g. "id is required for point at index 2".
Coordinate Systems
| System | EPSG | Description |
|---|---|---|
| WGS84 | EPSG:4326 | Geographic coordinate system used by GPS. Coordinates expressed as latitude and longitude in decimal degrees. |
| OSGB36 British National Grid | EPSG:27700 | Coordinate reference system used by Ordnance Survey for Great Britain. Coordinates expressed as easting and northing in metres. |
Limitations
- Designed for mainland Great Britain only.
- Not suitable for Ireland or Northern Ireland (use ITM or Irish Grid instead).
- Not suitable for the Channel Islands or other British Overseas Territories.
- Accuracy degrades at the edges of the coverage area.
- Not for survey-grade applications.
